 ну вот , 14 февраля 2014 года, а в википедии появился анонс о выходе 3ей версии.
Основное отличие от второй - наличие IDE хоста
Приобрести ее можно в магазине Linksprite за 77$
Hardware Specifications
| Items |
Details |
| CPU |
AllWinner A20 SoC, 1GHz ARM Cortex A7 Dual Core |
| GPU |
OpenGL ES2.0, OpenVG 1.1, Mali 400 Dual Core |
| DRAM |
1GB |
| Onboard Storage |
4GB Flash, microSD card (TF) slot for up to 32GB |
| Video Output |
HDMI 1.4 with HDCP support |
| OS |
|
| Arduino extension interface |
Arduino sockets, same as Arduino UNO
14xGPIO, 2xPWM, 6xADC, 1xUART, 1xSPI, 1xI2C |
| Network interface |
- Built-in WiFi
- Ethernet 10Mbps
|
| Audio out |
- 3.5mm analog audio interface
- I2S stereo digital audio interface
|
| LCD |
LVDS |
| IR |
IR receiver |
| SATA |
SATA Host socket |
| Camera |
MIPI |
| Battery |
Li-Poly Battery Interface |
| USB |
1 x USB host, 1xUSB OTG |
| Power |
5V, 2000mA |
| Overall Size |
121mm x 65mm |
Software Specifications
| Items |
Description |
| OS |
|
| Language |
|
| API |
- All the arduino shield pins are accessible with the provided API
- It consists of API to access the following interfaces:
- UART
- ADC
- PWM
- GPIO
- I2C
- SPI
|
| Programming language support |
- C, C++ with GNU tool chain
- Java with standard Android SDK
- Python
|
|
